Jetson TX2 Series
The Jetson TX2 series of modules provide up to 2.5x the performance of Jetson Nano. These bring power-efficient embedded AI computing to a range of use cases, from mass-market products with the reduced form-factor Jetson TX2 NX to specialized industrial environments with the rugged Jetson TX2i.
Technical specifications
| Specification | Jetson TX2 NX | Jetson TX2 4GB | Jetson TX2 | Jetson TX2i |
|---|---|---|---|---|
| AI performance | 1.33 TFLOPS | 1.33 TFLOPS | 1.33 TFLOPS | 1.26 TFLOPS |
| GPU | 256-core NVIDIA Pascal GPU | 256-core NVIDIA Pascal GPU | 256-core NVIDIA Pascal GPU | 256-core NVIDIA Pascal GPU |
| CPU | Dual-core NVIDIA Denver 2 64-bit + quad-core Arm Cortex-A57 MPCore | Dual-core NVIDIA Denver 2 64-bit + quad-core Arm Cortex-A57 MPCore | Dual-core NVIDIA Denver 2 64-bit + quad-core Arm Cortex-A57 MPCore | Dual-core NVIDIA Denver 2 64-bit + quad-core Arm Cortex-A57 MPCore |
| Memory | 4 GB 128-bit LPDDR4, 51.2 GB/s | 4 GB 128-bit LPDDR4, 51.2 GB/s | 8 GB 128-bit LPDDR4, 59.7 GB/s | 8 GB 128-bit LPDDR4 with ECC, 51.2 GB/s |
| Storage | 16 GB eMMC 5.1 | 16 GB eMMC 5.1 | 32 GB eMMC 5.1 | 32 GB eMMC 5.1 |
| Power | 7.5 W – 15 W | 7.5 W – 15 W | 7.5 W – 15 W | 10 W – 20 W |
| Connector | 260-pin SO-DIMM | 400-pin, integrated thermal transfer plate | 400-pin, integrated thermal transfer plate | 400-pin, integrated thermal transfer plate |
| Dimensions | 69.6 mm x 45 mm | 87 mm x 50 mm | 87 mm x 50 mm | 87 mm x 50 mm |
Source: NVIDIA – Jetson TX2
